Surface & Solid Design
CAD Video Training Products - Click Here

Why read the book when you can see the movie”

3D Surface Design & Solid Modeling In  Mastercam  X thru X7

TFM - 3D Design For X4 CD - Click Here To Order

Mastercam is a powerful 3D CAD tool. This CD covers 3D Surface Design and 3D Solid Modeling functions. Start with basic Surface creations and move up into complete part models. This CD will work with X thru X7

No Internet Connection Required. No Monthly Subscription. The CD Never Expires. Watch These Lessons Any Time That’s Convenient For You.

Qty              $175

Sample Parts Will Work For  Mastercam  X thru X7

Surface Design Functions Covered.

  • Introduction To Surfaces
  • Flat Boundary, Rectangular
  • Extruded Surface
  • Drafted Surface
  • Ruled & Lofted Surfaces
  • Revolved Surfaces
  • Swept Surfaces
  • Net Surfaces
  • Coons Surfaces
  • Primitive Cone, Sphere, Block
  • Extending Surfaces
  • Offset Surfaces
  • Trimming Surface to Surface
  • Trimming Surface to Curves
  • Fillets / Trimmed
  • Surface Normals
  • 3 Fillet  &  6 Corner Blend

First we start with a basic overview of Surfaces and Solids. Then we cover model creation, Step by Step, walking you thru every aspect of what you need to know.

    66 Lessons.
               14 Different Parts.
                             5 - 1/2 Hours of Video.

Includes  8  Tutorial  Workbooks.

Solid Modeling Functions Covered.

  • Introduction To Solids
  • Extruded & Drafted
  • Ruled & Lofted Solids
  • Revolved Solids
  • Sweep Solids
  • Solid Cut
  • Thin Walled Shell
  • Solid Fillets
  • Variable Radius Fillets
  • Chamfer Edges
  • Split Draft
  • Boolean Add
  • Boolean Remove
  • Boolean Common
  • Using The Solid Mgr. Tree

Geometry Functions Covered.

  • 2D Geometry Construction
  • 3D Geometry Construction
  • Transform (Xform)
  • Xform - Translate
  • Xform - Rotate
  • Xform - Mirror
  • Xform - Offset
  • Xform - Project
  • Create - Rectangle
  • Create - Rectangular Shapes
  • 3D Curves
  • Surface Edge Curves
  • 3 Point Arcs.
  • Working With Planes
  • Create Custom (tilted) Planes
  • 3rd Plane Z Depth Control
  • Changing Entity Colors
  • Changing Entity Levels
  • Geometry Selection Techniques

Personal, Professional Training
Anytime You Want It.

This CD Will Work For X thru X7 Users.
Developed in
Mastercam  X4

Qty              $175

No Internet Connection Required. No Monthly Subscription. The CD Never Expires. Watch These Lessons Any Time That’s Convenient For You.

This CD Rom runs in 1024 x 768 resolution. Easy to run on any PC. Contains 5-1/2 hours of video with audio narration.  A sound card & Speakers are required.
