Multiaxis Disk 2
CAD Video Training Products - Click Here

Why read the book when you can see the movie”

Multiaxis Toolpaths - Disk 2 For  Mastercam  X5

X5_MAxis_D2_CD_Md

This CD is the companion to the Multiaxis Disk 1.   1f you have 4 & 5 Axis Milling Machines, then you need the 2 disk set. Complete Multiaxis training for Mastercam  X5.

No Internet Connection Required. No Monthly Subscription. These CD’s Never Expire. Watch These Lessons Any Time That’s Convenient For You.

Qty              $175

Be Sure To Get Multiaxis Disk 1 Also

5th Axis Functions Covered In Disk 2.

  • 5 Axis Machine Types
  • Rotary Axis Designations
  • Introduction to Rotary Motion
  • Tool Control Options.
  • Tool Position From a Point
  • Tool Position To a Point
  • Tool Position With Line Vectors
  • Tool Position With Curve Control
  • Tool Position Thru Surface Normals
  • Tool Position Thru a Plane
  • Curve 5X Multi Surface Toolpath
  • 5 Axis Flowline
  • 5 Axis MultiSurface Flowline
  • Parallel Between 2 Curves
  • Morph Between 2 Curves
  • Swarf Side Cutting Toolpaths
  • Cylinder Port Machining
  • Turbine Blade Machining
  • Advanced Control Parameters
  • 5 Axis Roughing Options
  • Tilt Control Options
  • Backplot & Verify Options
  • Machine Simulation

Geometry Construction Techniques.

  • Importing Solid Models
  • Create Surfaces For Solid Models
  • Create Curves on Edges
  • Create Projected Curves
  • Creating Spline Curves
  • 3D Toolpath Line Vectors
  • Level Management
  • Color Control
  • Chaining Options
  • Synchronized Contour Chains
  • Chaining Tolerance Control
  • Selecting Chains by Level & Color
  • Creating Patch Surfaces
  • 5 Axis Setup Considerations

Step by Step Training.  Guiding you thru every lesson.

Multiaxis Disk 2 Contains
          63 Lessons.
                       9 Different Parts.
                                     4.5  Hours of Video.

The Multiaxis 2 CD Set Contains
          123 Lessons.
                       20 Different Parts.
                                      10  Hours of Video.

Personal, Professional Training
Anytime You Want It

Qty              $175

Dont forget to add Disk 1
Buy Both CD’s and get 10% off list price

Click Here For More Information On Disk 1.

No Internet Connection Required. No Monthly Subscription. The CD Never Expires. Watch These Lessons Any Time That’s Convenient For You.

This CD Rom runs in 1024 x 768 resolution. Easy to run on any PC. Contains 4-1/2 hours of video with audio narration.  A sound card & Speakers are required.
